VEGAMET 381

Application area

The VEGAMET 381 SIL controller powers the connected 4 … 20 mA/HART sensor, processes and displays the measured values. The VEGAMET 381 is ideal for simple control tasks in SIL and steam vessel applications. Comprehensive adjustment functions enable individual adaptations to the respective application.

Your benefit

Good readability of the LC display through digital and quasianalogue indication of the measured value
Transmitter power supply via the 4 … 20 mA sensor input
Can be used in SIL and steam boiler application by means of two relay output for limit value monitoring

SKU: VEGAMET 381

Add to Cart

Technical specifications

Protection rating	IP20/IP40
Input	1 x 4 … 20 mA sensor input
Output	1 x 0/4 … 20 mA current output 1 x fail safe relay 2 x operating relay
Ambient temperature	-20 … 60 °C
Signal input (specify)	4 … 20 mA
Signal output (specify)	4 … 20 mA Operating relay Fail safe relay Display
