| Series | RV-CR SERIES |
|---|---|
| Type | VERTICAL |
| Payload (kg) | 8 |
| Installation Method | FLOOR, CEILING, WALL |
| Speed (mm/s) | 10500 |
| Repeatability (mm) | 0,02 |
| Cycle Time (s) | 0,44 |
| Max. Reach Radius (mm) | 931 |
| Operating Range J1 (deg) | 340 |
| Operating Range J2 (deg) | 220 |
| Operating Range J3 (deg) | 165 |
| Operating Range J4 (deg) | 400 |
| Operating Range J5 (deg) | 240 |
| Operating Range J6 (deg) | 720 |
| Environment specification | STANDARD |
| Controller Type | CR800-D |
| Protection Class | IP65 |
| Power Supply 1 Phase (VAC) | 200-230 |
| Power Consumption (VA) | 2000 |
| Width (mm) | 280 |
|---|---|
| Height (mm) | 1020 |
| Depth (mm) | 865 |
| Weight (kg) | 41 |
| CE | COMPLIANT |
|---|---|
| UKCA | COMPLIANT |
| Cardboard (g) | 10000 |
|---|---|
| Other paper (g) | 0 |
| Aluminum (g) | 0 |
| Steel (g) | 70 |
| Styrofoam (g) | 0 |
| Other plastic (g) | 108,66 |
| Wood (g) | 0 |
| Glass (g) | 0 |
| Others (g) | 0 |
| REACH Limit Exceeded | YES |
|---|---|
| REACH Substance CAS Number | 556-67-2, 1303-86-2, 101-80-4, 7439-92-1, 80-05-7, 872-50-4 |
| Dangerous Goods Regulations | 9 |
| WEEE | B2B |
