$22,720.00
| Special feature | Free from silicone; Gold-plated contacts |
|---|---|
| Free from silicone | yes |
| Operating voltage [V] | 10…30 DC; (“supply class 2” to cULus) |
|---|---|
| Protection class | II |
| Max. current load per module/slot [A] | 4 |
| Max. current load total [A] | 12 |
| Ambient temperature [°C] | -25…70 |
|---|---|
| Ambient temperature (moving) [°C] | -5…60 |
| Protection | IP 67; IP 68 |
| UL approval |
|
|---|
| Weight [g] | 2875 |
|---|---|
| Dimensions [mm] | 22 x 54 x 127 |
| Materials | housing: PA |
| Number of ports splitter box | 8 |
| Connector type | M12 |
| Items supplied |
|
|---|
| Pack quantity | 1 pcs. |
|---|
| Cable: 15 m, PVC, black, Ø 9.7 mm; 16 x 0.34 mm² + 3 x 1.0 mm² |
| Connection | Connector: 8 x M12; coding: A; Contacts: gold-plated; Tightening torque: 0.8…1.5 Nm |
|---|
Datasheet
EN PDF
