Application
| Special feature |
Free from silicone; Halogen-free; Gold-plated contacts; Drag chain suitability |
| Free from silicone |
yes |
Electrical data
| Operating voltage [V] |
< 30 AC/DC; (“supply class 2” to cULus) |
| Protection class |
II |
| Max. current load per module/slot [A] |
4 |
| Max. current load total [A] |
12 |
Operating conditions
| Ambient temperature [°C] |
-25…80 |
| Ambient temperature (moving) [°C] |
-5…60 |
| Protection |
IP 67; IP 68 |
Mechanical data
| Weight [g] |
1470.5 |
| Dimensions [mm] |
22 x 54 x 100 |
| Materials |
PA |
| Moulded-body material |
PA |
| Number of ports splitter box |
6 |
| Connector type |
M12 |
| Drag chain suitability |
yes |
| Drag chain suitability |
| bending radius for flexible use |
min. 10 x cable diameter |
| bending cycles |
> 2 Mio. |
|
Accessories
| Items supplied |
| Protective caps: 2 |
| labels: 6 |
|
Electrical connection – plug
|
Connector: 1 x M23, angled; Moulded body: PA; Contacts: gold-plated; Tightening torque: 0.8…1.5 Nm |
Electrical connection
| Connection |
Cable: 10 m, PUR, Halogen-free, black, Ø 8.8 mm; 12 x 0.34 mm² (63 x Ø 0.1 mm ) + 3 x 1.0 mm² (127 x Ø 0.1 mm ) |
Electrical connection – slot
|
Connector: 6 x M12; coding: A; Moulded body: PA; Contacts: gold-plated; Tightening torque: 0.8…1.5 Nm |
