Application
| Special feature |
Gold-plated contacts |
Electrical data
| Operating voltage [V] |
15…30 DC; (“supply class 2” to cULus) |
| Protection class |
III |
| Max. current load per module/slot [A] |
2 |
| Max. current load total [A] |
2 |
Operating conditions
| Ambient temperature [°C] |
-25…80 |
| Ambient temperature (moving) [°C] |
-5…60 |
| Protection |
IP 67; IP 68; (1 m / 7 days) |
Mechanical data
| Weight [g] |
150.5 |
| Materials |
PBT-GF20; brass nickel-plated |
| Moulded-body material |
PBT-GF 20 / brass, nickel-plated |
| Number of ports splitter box |
10 |
| Connector type |
M8 |
Displays / operating elements
| Display |
| switching status |
10 x LED, yellow |
| operation |
1 x LED, green |
|
Accessories
| Accessories (optional) |
| Protective cap: M8, E73005 |
|
Electrical connection – plug
| Connection |
Connector: 1 x M12; Moulded body: PBT-GF 20 / brass, nickel-plated; Contacts: gold-plated; Tightening torque: 0.8…1.5 Nm |
Electrical connection – socket
|
Connector: 1 x M8; coding: A; Moulded body: PBT-GF 20 / brass, nickel-plated; Contacts: gold-plated; Tightening torque: 0.8…1.5 Nm |
