| Design | potential module GND (10 x 2,5 mm²) |
|---|
| Operating voltage [V] | 18…30 DC |
|---|---|
| Nominal voltage DC [V] | 24 |
| Protection class | III |
| Max. load current [A] | 20 |
| Ambient temperature [°C] | -25…60 |
|---|---|
| Storage temperature [°C] | -40…70 |
| Protection | IP 20 |
| EMC |
|
|---|
| Weight [g] | 62.5 |
|---|---|
| Type of mounting | mounting on DIN rail |
| Installation instruction | string mounting possible |
| Dimensions [mm] | 80 x 12.5 x 98.5 |
| Connection | push-in terminals: |
|---|
Datasheet
EN PDF
