| Process temperature |
-50 … 250 °C [°C – °F]
|
| Process pressure |
-1 … 64 bar [Bar – kPa – psi]
|
| Version |
Standard
Hygienic applications
with gas-tight leadthrough
with tube extension
with temperature adapter
|
| Materials, wetted parts |
PFA
316L
Alloy C22 (2.4602)
Alloy 400 (2.4360)
ECTFE
Enamel
|
| Threaded connection |
≥ G¾, ≥ ¾ NPT
|
| Flange connection |
≥ DN25, ≥ 1″
|
| Hygenic fittings |
Clamp ≥ 1″ – DIN32676, ISO2852
Slotted nut ≥ 1½”, ≥ DN40 – DIN 11851
Varivent ≥ DN25
hygienic fitting F40 with compression nut
SMS 1145 DN51
SMS DN38
Hygienic fittings ≥ DN25 – DIN11864-1-A
Hygienic flange connection DIN11864-2-A; DN60(ISO)ø60,3
SMS socket piece DN38 PN6
|
| Seal material |
no media contact
|
| Housing material |
Plastic
Aluminium
Stainless steel (precision casting)
Stainless steel (electropolished)
|
| Protection rating |
IP66/IP67
IP66/IP68 (1 bar)
IP65
|
| Output |
Relay (DPDT)
Contactless electronic switch
Transistor (NPN/PNP)
Two-wire
NAMUR
|
| Ambient temperature |
-40 … 70 °C
|
| Scope |
ATEX / Europe
CSA / Canada
FM / USA
EAC (GOST) / Belarus
EAC (GOST) / Kazakhstan
EAC (GOST) / Russia
IEC / worldwide
KOSHA / Korea
NEPSI / China
UKR Sepro / Ukraine
INMETRO / Brazil
CCOE / India
|
| Explosion protection |
Intrinsic safety “i”
Flameproof enclosure “d”
Dust explosion protection through housing “t”
|
| Foodstuffs/Pharma |
3A
EHEDG
FDA
|
| Ship approval |
ABS
BV
CCS
DNV
GL
LR
RINA
RMROS
|
| Overfill protection |
WHG
VLAREM II
|
| SIL qualification |
SIL2
|
| Indication |
Pluggable display module PLICSLED
|
