For this instrument, new radar sensors with connection housing VEGAPULS 11, 21 or 31, or radar sensors with fixed connected cable VEGAPULS C 11, C 21, C 22 or C 23 are available as alternative.
| Measuring range – Distance |
5 m [Meter – Foot]
|
| Process temperature |
-40 … 80 °C [°C – °F]
|
| Process pressure |
-0.2 … 2 bar [Bar – kPa – psi]
|
| Accuracy |
± 4 mm
|
| Materials, wetted parts |
PVDF
|
| Threaded connection |
≥ G1½, ≥ 1½ NPT
|
| Hygenic fittings |
Clamp ≥ 2″, DN50 – DIN32676, ISO2852
Clamp ≥ 3″, DN65 – DIN32676, ISO2852
Clamp ≥ 3½” , DN80 – DIN32676, ISO2852
Clamp ≥ 4″ , DN100 – DIN32676, ISO2852
Slotted nut ≥ 3″, DN65 – DIN 11851
Slotted nut ≥ 3½”, ≥ DN80 – DIN 11851
Slotted nut ≥ 4″, ≥ DN100 – DIN 11851
|
| Seal material |
EPDM
FKM
|
| Housing material |
Plastic
Aluminium
Stainless steel (precision casting)
Stainless steel (electropolished)
|
| Protection rating |
IP66/IP68 (0,2 bar)
IP66/IP67
IP66/IP68 (1 bar)
|
| Output |
Profibus PA
Foundation Fieldbus
4 … 20 mA/HART – two-wire
4 … 20 mA/HART – four-wire
|
| Ambient temperature |
-40 … 80 °C
|
| Scope |
ATEX / Europe
CSA / Canada
FM / USA
EAC (GOST) / Belarus
EAC (GOST) / Kazakhstan
EAC (GOST) / Russia
IEC / worldwide
NEPSI / China
UKR Sepro / Ukraine
INMETRO / Brazil
|
| Explosion protection |
Intrinsic safety “i”
|
| Ship approval |
ABS
CCS
DNV
GL
LR
RINA
|
| SIL qualification |
SIL2
|
| Adjustment |
PLICSCOM
PC, PACTware and DTM
HART-Communicator
Software (e. g. AMS™, PDM)
|
| Indication |
Display/adjustment module PLICSCOM
VEGADIS 81
VEGADIS 82
|
