| Measuring range – Distance |
100 m [Meter – Foot]
|
| Process temperature |
-40 … 80 °C [°C – °F]
|
| Process pressure |
-1 … 4 bar [Bar – kPa – psi]
|
| Version |
hygienically encapsulated horn antenna
for separate horn antenna
with horn antenna ø 40 mm
with horn antenna ø 48 mm
with horn antenna ø 75 mm
with horn antenna ø 95 mm
with plastic horn antenna ø 80 mm
Horn antenna ø 1½”
with encapsulated horn antenna
|
| Materials, wetted parts |
PTFE
316L
1.4848
PP
|
| Threaded connection |
G1½, 1½ NPT
|
| Flange connection |
≥ DN50, ≥ 2″
|
| Hygenic fittings |
Slotted nut ≥ 2″, DN50 – DIN 11851
Varivent ≥ DN25
DRD connection ø 65 mm
for NEUMO BioControl D50 PN16 / 316L
|
| Seal material |
FKM
FFKM
|
| Housing material |
Plastic
Aluminium
Stainless steel (precision casting)
Stainless steel (electropolished)
|
| Protection rating |
IP66/IP68 (0,2 bar)
IP66/IP67
|
| Ambient temperature |
-40 … 80 °C
|
| Scope |
ATEX / Europe
CSA / Canada
FM / USA
EAC (GOST) / Belarus
EAC (GOST) / Kazakhstan
EAC (GOST) / Russia
IEC / worldwide
NEPSI / China
UKR Sepro / Ukraine
|
| Explosion protection |
Flameproof enclosure “d”
Dust explosion protection through housing “t”
|
| Indication |
Pluggable display module PLICSLED
|
