$57,380.00
| Resolution | 4096 steps; 4096 revolutions; 24 bit |
|---|---|
| Communication interface | CAN |
| Shaft design | solid shaft |
| Shaft diameter [mm] | 10 |
| Function principle | absolute |
|---|---|
| Revolution type | multiturn |
| Operating voltage [V] | 9…30 DC |
|---|---|
| Current consumption [mA] | < 100; ((10 V DC) ; ≤ 50 (24 V DC)) |
| Protection class | III |
| Reverse polarity protection | yes |
| Short-circuit protection | yes |
|---|---|
| Code | binary |
| Resolution | 4096 steps; 4096 revolutions; 24 bit |
|---|
| Accuracy [°] | 0.08 |
|---|
| Parameter setting options | CAN parameter; scaling; preset; Baud rate; direction of rotation; Node ID |
|---|
| Communication interface | CAN |
|---|
| Protocol | CANopen | ||
|---|---|---|---|
| Factory settings |
|
||
| Version | DSP – 406 |
| Ambient temperature [°C] | -40…85 |
|---|---|
| Protection | IP 68; IP 69K |
| Shock resistance |
|
||
|---|---|---|---|
| Vibration resistance |
|
||
| MTTF [years] | 240 |
| Weight [g] | 469 | |
|---|---|---|
| Dimensions [mm] | Ø 42 / L = 107.9 | |
| Materials | flange: stainless steel (1.4404 / 316L); housing: stainless steel (1.4404 / 316L) | |
| Max. revolution, mechanical [U/min] | 6000 | |
| Max. starting torque [Nm] | 5 | |
| Reference temperature torque [°C] | 20 | |
| Shaft design | solid shaft | |
| Shaft diameter [mm] | 10 | |
| Shaft material |
|
|
| Max. shaft load axial (at the shaft end) [N] | 180 | |
| Max. shaft load radial (at the shaft end) [N] | 180 | |
| Fixing flange | synchro-flange |
| Display |
|
|---|
| Connector: 1 x M12, axial; coding: A; Moulded body: stainless steel (316 / 1.4401) |
