$36,020.00
| Laser protection class | 2 |
|---|
| Special feature | Background suppression |
|---|
| Operating voltage [V] | 18…30 DC |
|---|---|
| Current consumption [mA] | < 150 |
| Protection class | III |
| Reverse polarity protection | yes |
| Typ. lifetime [h] | 50000 |
| Number of inputs and outputs | Number of digital outputs: 1 |
|---|
| Total number of outputs | 1 |
|---|---|
| Electrical design | NPN |
| Number of digital outputs | 1 |
| Output function | normally open / normally closed; (programmable) |
| Max. current load per output [mA] | 200 |
| Short-circuit protection | yes |
| Type of short-circuit protection | pulsed |
| Overload protection | yes |
| Max. light spot width [mm] | 15 |
|---|---|
| Max. light spot height [mm] | 15 |
| Light spot dimensions refer to | 10 m |
| Background suppression available | yes |
| Background suppression [m] | 10…100 |
| Measuring range [m] | 0.2…10; (white paper 200 x 200 mm 90% remission) |
|---|---|
| Sampling rate [Hz] | 5 |
| Communication interface | IO-Link |
|---|---|
| Transmission type | COM2 (38,4 kBaud) |
| IO-Link revision | 1.1 |
| Profiles | Smart Sensor: Sensor Identification; Binary Data Channel; Process Value; Sensor Diagnosis |
| SIO mode | yes |
| Required master port type | A |
| Process data analogue | 2 |
| Process data binary | 1 |
| Min. process cycle time [ms] | 6 |
| Ambient temperature [°C] | -10…60 |
|---|---|
| Protection | IP 67 |
| Laser protection class | 2 | ||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Notes on laser protection |
|
||||||||||||||||||||
| MTTF [years] | 106 |
| Weight [g] | 285.5 |
|---|---|
| Dimensions [mm] | 59 x 42 x 52 |
| Materials | housing: diecast zinc; front pane: glass; LED window: PC |
| Display |
|
|---|
| Accessories (optional) |
|
|---|
| Remarks |
|
|
|---|---|---|
| Pack quantity | 1 pcs. |
| Connection | Connector: 1 x M12; coding: A |
|---|
Datasheet
EN PDF
