$14,980.00
| Number of inputs and outputs | Number of digital outputs: 2 |
|---|---|
| Factory setting | water; hydrous media |
| Process connection | 1/2″ NPT |
| Special feature | Gold-plated contacts |
|---|---|
| Media | water; hydrous media; oils; oil-based media; coolants; powder |
| Cannot be used for | See the operating instructions, chapter “Function and features”. |
| Medium temperature [°C] | -25…100 |
| Probe length [mm] | 25 |
| Tank pressure [bar] | -1…40 |
| MAWP (for applications according to CRN) [bar] | 40 |
| Medium temperature [°C] | -25…100 |
|---|
| Operating voltage [V] | 18…30 DC |
|---|---|
| Current consumption [mA] | < 35 |
| Protection class | III |
| Reverse polarity protection | yes |
| Number of inputs and outputs | Number of digital outputs: 2 |
|---|
| Total number of outputs | 2 |
|---|---|
| Output signal | switching signal; IO-Link |
| Electrical design | PNP/NPN |
| Number of digital outputs | 2 |
| Output function | normally open / normally closed; (parameterisable) |
| Max. voltage drop switching output DC [V] | 2.5 |
| Permanent current rating of switching output DC [mA] | 50; (100 (…60 °C)) |
| Short-circuit protection | yes |
| Type of short-circuit protection | thermal, pulsed |
| Overload protection | yes |
| Factory setting | water; hydrous media |
|---|
| Response time [s] | < 0.5 |
|---|
| Communication interface | IO-Link | ||||
|---|---|---|---|---|---|
| Transmission type | COM2 (38,4 kBaud) | ||||
| IO-Link revision | 1.1 | ||||
| SDCI standard | IEC 61131-9 | ||||
| Profiles | Smart Sensor: Process Data Variable; Device Identification, Device Diagnosis | ||||
| SIO mode | yes | ||||
| Required master port type | A | ||||
| Process data analogue | 1 | ||||
| Process data binary | 2 | ||||
| Min. process cycle time [ms] | 2.3 | ||||
| Supported DeviceIDs |
|
| Ambient temperature [°C] | -25…85 |
|---|---|
| Storage temperature [°C] | -40…85 |
| Protection | IP 68; IP 69K; (7 days / 1 m water depth / 0.1 bar: IP 68) |
| EMC |
|
||||||
|---|---|---|---|---|---|---|---|
| Shock resistance |
|
||||||
| Vibration resistance |
|
||||||
| MTTF [years] | 534 | ||||||
| UL approval |
|
| Weight [g] | 116 |
|---|---|
| Dimensions [mm] | Ø 18.11 / L = 76.2 |
| Materials | stainless steel (1.4404 / 316L); PEEK; PEI; FKM |
| Materials (wetted parts) | stainless steel (1.4404 / 316L); PEEK; FKM |
| Process connection | 1/2″ NPT |
| Display |
|
|---|
| Pack quantity | 1 pcs. |
|---|
| Connection | Connector: 1 x M12; coding: A; Contacts: gold-plated |
|---|
