| Series | MELSEC-F SERIES |
|---|---|
| Type | FX2N |
| Occupied I/O Points on PLC | 8 |
| Integrated Analogue Inputs | 2 |
| Input Voltage Range (V) | 0-10; 0-5 |
| Input Current Range (mA) | 4-20 |
| Min. Ambient Temperature (°C) | 0 |
| Max. Ambient Temperature (°C) | 55 |
| Width (mm) | 43 |
|---|---|
| Height (mm) | 90 |
| Depth (mm) | 87 |
| Weight (kg) | 0,3 |
| CE | COMPLIANT |
|---|---|
| UL/cUL | COMPLIANT |
| EAC | COMPLIANT |
| Shipping Approvals | ABS,DNV GL,KR,NK |
| UKCA | COMPLIANT |
| Cardboard (g) | 38 |
|---|---|
| Other paper (g) | 0 |
| Aluminum (g) | 0 |
| Steel (g) | 0 |
| Styrofoam (g) | 0 |
| Other plastic (g) | 0 |
| Wood (g) | 0 |
| Glass (g) | 0 |
| Others (g) | 0 |
| REACH Limit Exceeded | NO |
|---|---|
| Dangerous Goods Regulations | NO |
| RoHS Compliance | COMPLIANT |
| WEEE | B2B |
