Interfaces
GNSS
| Frequency band |
1575,42…1610 MHz |
| Connector type |
SMA |
| Note on interfaces |
| Operating voltage: 3…5 V DC |
| Current consumption: < 15 mA |
| Impedance: 50 Ohm |
| Polarisation: RHCP |
| LNA: 28 ± 2 dB |
| LNA V.S.W.R.: < 2,0 |
| noise density: < 1,5 dB |
|
Mobile networks
| Transmission standard |
LTE Cat-4 |
| Frequency band |
LTE: 698…960 MHz; 1710…2690 MHz |
| Connector type |
SMA |
| Note on interfaces |
| Impedance: 50 Ohm |
| Polarisation: linear vertical |
|
|
WLAN
| Frequency band |
2400…2483,5 MHz; 4900…5825 MHz |
| Connector type |
SMA |
| Note on interfaces |
| Impedance: 50 Ohm |
| Polarisation: linear |
| noise density: 2 dBi |
|
|
Operating conditions
| Ambient temperature [°C] |
-40…85 |
| Protection |
IP 67 |
Mechanical data
| Weight [g] |
597.5 |
| Type of mounting |
screw mounting |
| Dimensions [mm] |
Ø 110 / L = 55 |
| Materials |
ABS |
Electrical connection – GPS
|
Cable: 3 m |
|
Connector: 1 x SMA |
Electrical connection – Mobile networks
|
Cable: 3 m |
|
Connector: 2 x SMA |
Electrical connection – WLAN
|
Cable: 3 m |
|
Connector: 2 x SMA |
