$13,330.00
| Special feature | Free from silicone; Gold-plated contacts |
|---|---|
| Free from silicone | yes |
| Operating voltage [V] | 10…30 DC |
|---|---|
| Max. current load per module/slot [A] | 2 |
| Max. current load total [A] | 12 |
| Electrical design | PNP |
|---|
| Ambient temperature [°C] | -25…80 |
|---|---|
| Ambient temperature (moving) [°C] | -5…60 |
| Protection | IP 67 |
| Weight [g] | 404.5 |
|---|---|
| Dimensions [mm] | 49.4 x 60 x 187 |
| Materials | brass nickel-plated; housing: PBT-GF30 |
| Number of ports splitter box | 8 |
| Connector type | M12 |
| Items supplied |
|
|---|
| Pack quantity | 1 pcs. |
|---|
| Connection | terminals, signal: 16 x 0.34…0.75 mm²; Cable gland: M20x1.5 |
|---|---|
| Connection | Connector: 1 x M12; coding: A; Contacts: gold-plated; Tightening torque: 0.8…1.5 Nm |
| Connector: 8 x M12; Contacts: gold-plated; Tightening torque: 0.8…1.5 Nm |
