Application
| Special feature |
Free from silicone; Gold-plated contacts |
| Free from silicone |
yes |
Electrical data
| Operating voltage [V] |
10…30 DC; (“supply class 2” to cULus) |
| Max. current load per module/slot [A] |
4 |
| Max. current load total [A] |
10 |
Operating conditions
| Ambient temperature [°C] |
-25…80 |
| Protection |
IP 67 |
Mechanical data
| Weight [g] |
256.5 |
| Materials |
PA |
| Moulded-body material |
PA |
| Number of ports splitter box |
6 |
| Connector type |
M12 |
Displays / operating elements
| Display |
| switching status |
12 x LED, yellow |
| operation |
1 x LED, green |
|
Accessories
| Items supplied |
| Protective caps: 2 |
| labels: 6 |
|
Electrical connection – Connection
| Connection |
Connector: 1 x M23; Moulded body: PA; Contacts: gold-plated; Tightening torque: 0.8…1.5 Nm |
Electrical connection – slot
|
Connector: 6 x M12; coding: A; Moulded body: PA; Contacts: gold-plated; Tightening torque: 0.8…1.5 Nm |
