Application
| Special feature |
Free from silicone; Halogen-free; Gold-plated contacts; Drag chain suitability |
| Free from silicone |
yes |
Electrical data
| Operating voltage [V] |
9.6…30 DC |
| Protection class |
III |
| Max. current load total [A] |
3 |
Operating conditions
| Ambient temperature [°C] |
-25…85 |
| Protection |
IP 67; IP 69K |
Mechanical data
| Weight [g] |
100.5 |
| Dimensions [mm] |
10 x 10 x 31 |
| Materials |
housing: TPU orange; Sealing: FKM; housing: Hytrel G-4774 black |
| Material nut |
brass, nickel-plated |
| Drag chain suitability |
yes |
| Drag chain suitability |
| bending radius for flexible use |
min. 10 x cable diameter |
| travel speed |
max. 3.3 m/s for a horizontal travel length of 5 m and max. acceleration of 5 m/s² |
| bending cycles |
> 5 Mio. |
| torsional strain |
± 180 °/m |
|
Electrical connection – socket
|
Connector: 1 x M8, straight; coding: A; Locking: brass, nickel-plated; Contacts: gold-plated; Tightening torque: 0.3…0.5 Nm |
Electrical connection
| Connection |
Cable: 3.7 m, PUR, Halogen-free, black, Ø 3.7 mm; 3 x 0.25 mm² (32 x Ø 0.1 mm ) |
Electrical connection – socket
|
Connector: 1 x bayonet, straight; Locking: brass, nickel-plated; Contacts: gold-plated; Tightening torque: 0.3…0.5 Nm |
