$18,490.00
| Application | detection of objects on transport equipment | |
|---|---|---|
| Radio approval for | USA; Canada; EU/RED; Australia; Japan; China; Taiwan; India; Malaysia | |
| Note on radio approval |
|
| Operating voltage [V] | 18…30 DC |
|---|---|
| Current consumption [mA] | < 60 |
| Protection class | III |
| Operating frequency [MHz] | 13,56 |
| RFID standard | ISO 15693 |
| Distance write/read head front [mm] | 170 | |||
|---|---|---|---|---|
| Distance write/read head side [mm] | 160 | |||
| Distance to the ID tag [mm] |
|
| Communication interface | IO-Link | ||||
|---|---|---|---|---|---|
| Transmission type | COM2 (38,4 kBaud) | ||||
| IO-Link revision | 1.1 | ||||
| SDCI standard | IEC 61131-9 | ||||
| Profiles | Smart Sensor: Device Identification | ||||
| SIO mode | no | ||||
| Required master port type | A | ||||
| Supported DeviceIDs |
|
| Ambient temperature [°C] | -20…60 |
|---|---|
| Storage temperature [°C] | -25…80 |
| Protection | IP 67; IP 69K |
| Shock resistance |
|
||||||||
|---|---|---|---|---|---|---|---|---|---|
| Vibration resistance |
|
||||||||
| UL approval |
|
| Weight [g] | 77.5 |
|---|---|
| Housing | rectangular |
| Mounting | non-flush mountable |
| Dimensions [mm] | 20 x 7 x 48 |
| Materials | PBT; TPU; stainless steel |
| Display |
|
|---|
| Pack quantity | 1 pcs. |
|---|
| Cable: 1 m, PUR; 3 x 0.14 mm² |
| Connection | Connector: 1 x M12; coding: A |
|---|
Datasheet
EN PDF
