| Application | detection of objects on transport equipment | |
|---|---|---|
| Radio approval for | USA; Canada; EU/RED; Australia; Singapore; China | |
| Note on radio approval |
|
| Operating voltage [V] | 26.5…31.6 DC |
|---|---|
| Current consumption [mA] | < 75 |
| Protection class | III |
| Operating frequency [MHz] | 0,125 |
| Electrical design | AS-i |
|---|
| Travel speed [m/s] | < 0.5 | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Distance read/read head front | 150 | |||||||||
| Distance read/read head side | 150 | |||||||||
| Note on distance read/read head |
|
|||||||||
| Distance write/read head front [mm] | 300 | |||||||||
| Distance write/read head side [mm] | 300 | |||||||||
| Note on distance write/read head |
|
|||||||||
| Distance to the ID tag [mm] |
|
| Communication interface | AS-i |
|---|
| Ambient temperature [°C] | -20…60 |
|---|---|
| Storage temperature [°C] | -25…80 |
| Protection | IP 67; IP 69K |
| EMC |
|
||||
|---|---|---|---|---|---|
| Shock resistance |
|
||||
| Vibration resistance |
|
||||
| MTTF [years] | 456 |
| AS-i I/O configuration [hex] | 7 |
|---|---|
| AS-i ID code [hex] | 3 |
| AS-i certificate | 87202 |
| Weight [g] | 168.4 |
|---|---|
| Housing | rectangular |
| Sensing face | 5 positions selectable |
| Dimensions [mm] | 40 x 40 x 54 |
| Materials | PA |
| Display |
|
|---|
| Remarks |
|
|
|---|---|---|
| Pack quantity | 1 pcs. |
| Connection | Connector: 1 x M12, rotatable, locking; coding: A |
|---|
