| Electrical design | PNP/NPN |
|---|---|
| Output function | normally open / normally closed; (parameterisable) |
| Communication interface | IO-Link |
| Dimensions [mm] | 63 x 30 x 24 |
| Operating voltage [V] | 18…30 DC; (to SELV/PELV) |
|---|---|
| Nominal voltage DC [V] | 24 |
| Current consumption [mA] | < 380 |
| Max. current load total [A] | 0.2 |
| Number of inputs and outputs | Number of digital inputs: 2; Number of digital outputs: 2 |
|---|
| Number of digital inputs | 2; (Zähleingang: 1; Zählrichtung/Latch: 1; IEC61131-2) |
|---|---|
| Input current limitation [mA] | 200 |
| Electrical design | PNP/NPN |
|---|---|
| Number of digital outputs | 2 |
| Output function | normally open / normally closed; (parameterisable) |
| Short-circuit proof | yes |
| Sampling rate [Hz] | < 2000 |
|---|
| Communication interface | IO-Link | ||||
|---|---|---|---|---|---|
| Transmission type | COM2 (38,4 kBaud) | ||||
| IO-Link revision | 1.1 | ||||
| SDCI standard | IEC 61131-9 | ||||
| Profiles | Smart Sensor: Measuring Sensor (High resolution, Disable function); Identification and Diagnosis; Switching Signal Channel; Adjustable Switching Signal Channel | ||||
| SIO mode | yes | ||||
| Required master port type | A | ||||
| Process data binary | 1 | ||||
| Min. process cycle time [ms] | 6.1 | ||||
| Supported DeviceIDs |
|
| Ambient temperature [°C] | -25…60 | |||
|---|---|---|---|---|
| Note on ambient temperature |
|
|||
| Storage temperature [°C] | -25…60 | |||
| Max. relative air humidity [%] | 90; (linearly decreasing to 50 % (40 °C) non condensing) | |||
| Max. height above sea level [m] | 4000 | |||
| Protection | IP 67 | |||
| Pollution degree | 2 |
| MTTF [years] | 317 |
|---|
| Weight [g] | 84.2 |
|---|---|
| Weight (without accessories and packaging) [g] | 35 |
| Dimensions [mm] | 63 x 30 x 24 |
| Materials | housing: PA |
| Display |
|
||||||
|---|---|---|---|---|---|---|---|
| Operating elements |
|
| Accessories (optional) |
|
|---|
| Remarks |
|
|
|---|---|---|
| Pack quantity | 1 pcs. |
| main counter | 0…1000000 cnt |
| batch counter: | 0…9999 bcnt |
