Electrical data
| Operating voltage [V] |
12…27 DC |
| Current consumption [mA] |
11…48 |
Interfaces
| Communication interface |
CAN |
| Number of CAN interfaces |
2 |
CAN
| Transmission rate |
250 (125…1000) kBaud |
| Interface |
CAN Interface 2.0 A/B ISO 11898 |
| Terminating resistor |
yes; (internal ; 120 Ohm; cannot be deactivated) |
ISOBUS
| Transmission rate |
250 kBaud |
| Interface |
CAN Interface ISO 11783 |
| Terminating resistor |
no |
Operating conditions
| Ambient temperature [°C] |
-40…80 |
| Protection |
IP 67 |
Mechanical data
| Weight [g] |
190.1 |
| Type of mounting |
panel / surface |
| Dimensions [mm] |
72 x 104 x 29 |
| Materials |
housing: PA 12 black |
Displays / operating elements
| Display |
| status |
1 x LED, green/red |
| supply voltage |
1 x LED, green/red |
|
Hardware
| Processor |
ARM Cortex M4 32 bit |
| Program memory |
1,5 MB Flash |
| Working memory |
RAM: 320 kBFRAM: 16 kB |
Electrical connection – CAN
|
Connector: 1 x M12; coding: A |
Electrical connection – ISOBUS
|
Connector: 1 x M12; coding: A |
