$19,320.00
| Design | only for operation with AS-i masters with the profile M4 |
|---|---|
| Application | field installation |
| Operating voltage [V] | 26.5…31.6 DC |
|---|---|
| Max. current consumption from AS-i [mA] | 300 |
| Reverse polarity protection | yes |
| Additional voltage supply [V] | 20…30 DC |
| Sensor supply of the inputs | AS-i |
|---|---|
| Digital inputs protected against short circuits | yes |
| Communication interface | IO-Link; AS-i |
|---|
| Min. process cycle time [ms] | 2.3 |
|---|
| Transmission type | COM1 (4,8 kBaud); COM2 (38,4 kBaud) |
|---|---|
| IO-Link revision | 1.0 |
| Number of ports class A | 2 |
| Ambient temperature [°C] | -25…70 |
|---|---|
| Protection | IP 67 |
| EMC |
|
||
|---|---|---|---|
| MTTF [years] | 149 |
| AS-i version | 3.0 |
|---|---|
| AS-i addressing | addressing socket |
| Extended addressing mode | no |
| AS-i profile | S-7.5.5 |
| AS-i I/O configuration [hex] | 7 |
| AS-i ID code [hex] | 5.5 |
| Weight [g] | 161.35 |
|---|---|
| Materials | PA; piercing contacts: CuSn6 nickel-plated and tin-plated |
| Display |
|
|---|
| Module connection | Flat cables |
|---|
| Items supplied |
|
|
|---|---|---|
| Accessories (optional) |
|
| Remarks |
|
|||
|---|---|---|---|---|
| Pack quantity | 1 pcs. |
| quick mounting technology for AS-i flat cable: ; three orientations possible | |
| Connector: M12; coding: A |
