$31,910.00
| Nominal voltage AC [V] | 110 / 230 |
|---|---|
| Nominal frequency AC [Hz] | 47…63 |
| Input voltage range AC [V] | 85…132 / 184…264 |
| Overvoltage protection | yes; (< 55 V) |
| Max. power-on delay time [ms] | 100 |
| Output voltage AS-i [V] | 29.5…31.6; (to PELV; NEC Class II) |
| Output power (permanent) [W] | 85 |
| Number of output circuits | 1 |
| Output current AS-i [A] | 2.8 |
| Max. residual ripple [mV] | 50 |
| External input protection | > 6 A |
| Derating [W/K] | 2 (60…70 °C) |
| Integrated data decoupling | yes |
| Short-circuit protection | yes |
|---|---|
| Type of short-circuit protection | electronically protected |
| Overload protection | yes |
| Parallel connection of outputs possible | no |
| Series connection of outputs possible | no |
| Ambient temperature [°C] | -10…70 |
|---|---|
| Protection | IP 20 |
| EMC |
|
||||||||
|---|---|---|---|---|---|---|---|---|---|
| MTTF [years] | 222 |
| AS-i certificate | 54401 |
|---|
| Weight [g] | 573.5 |
|---|---|
| Materials | aluminium; steel sheet galvanised |
| Display |
|
|---|
| Pack quantity | 1 pcs. |
|---|
| Connection | cage clamps: |
|---|
Datasheet
EN PDF
