MX inverter drive, 7.5/11.0 kW (HD/ND), 33/40 A (HD/ND), 200 VAC, 3~ input, sensorless vector, max. output freq. 580Hz
| Drive control method | Open loop V/f, Open loop vector |
| Drive supply voltage | 230 V three phase |
| Max. motor output at constant torque (HD) | 7.5 kW |
| Max. motor output at variable torque (ND) | 11 kW |
| Built in EMC filter | ❌ |
| Degree of protection (IP) | IP20 |
| Finless type | ❌ |
| Compatible motor type | Induction or asynchronous motor, Permanent magnet motor |
| Regenerative solutions | As inverter option |
| Communication port(s) | MODBUS Slave, Serial RS-485, USB |
| Communication option(s) | CompoNet Slave, DeviceNet Slave, EtherCAT Slave, EtherNet/IP, MECHATROLINK II Slave, PROFIBUS DP Slave |
 |
3G3AX-MX2-DRT-E | DeviceNet option card for MX2 inverter |
|
 |
3G3AX-MX2-ECT | MX2 EtherCAT option card |
|
 |
3G3AX-MX2-EIP-A | MX2 Ethernet/IP option card |
|
 |
3G3AX-MX2-PRT-E | MX2 option card, PROFIBUS DP |
|
 |
3G3AX-OP01 | LED remote operator panel, cable length max. 3m |
|
 |
3G3AX-OP05 | 5 line LCD digital operator with copy function |
|
| AX-FER2815-PE | Ferrite choke, 28mm diameter, for 15kW inverters and below |
|
|
 |
AX-FIC4080-SE | Common footprint RFI filter for Compact series (Q2V/V1000/J1000/MX2), 80 A, 400 VAC, three phase, for 18.5 kW and 22 kW drives. |
|
| AX-FIC4080-SE-LL | Low Leakage common footprint RFI filter for Compact series (Q2V/V1000/J1000/MX2), 80 A, 400 VAC, three phase, for 18.5 kW and 22 kW drives. |
|
|
| AX-RAO00950320-DE | AC output reactor, 32 A, 0.95 mH, for 7.5 kW, 200 VAC, 3 phase |
|
|
 |
AX-REM01K9017-IE | Braking resistor, 17 ohm, 1900 W nominal |
|
Datasheet
EN PDF
MX inverter drive, 0.75/1.1 kW (HD/ND), 5.0/6.0 A (HD/ND), 200 VAC, 3~ input, sensorless vector, max. output freq. 580Hz
MX inverter drive, 7.5/11.0 kW (HD/ND), 18/23 A (HD/ND), 400 VAC, 3~, sensorless vector, max. output freq. 580Hz
MX inverter drive, 0.4/0.55 kW (HD/ND), 3.0/3.5 A (HD/ND), 200 VAC, 3~ input, sensorless vector, max. output freq. 580Hz
MX inverter drive, 0.2/0.4 kW (HD/ND), 1.6/1.9 A (HD/ND), 200 VAC, 3~ input, sensorless vector, max. output freq. 580Hz
