Spherical roller thrust bearings accommodate very heavy axial and considerable radial loads. They have the highest load rating of all thrust bearings, enabling compact, high power density bearing arrangements. By combining two or more spherical roller thrust bearings, it is possible to create a bearing arrangement that is either self-aligning, allowing misalignment of the shaft, or very stiff.
| d |
800 mm
|
Bore diameter |
|---|---|---|
| D |
1 360 mm
|
Outside diameter |
| H |
335 mm
|
Height |
| d1 |
≈ 1 250 mm
|
Outside diameter of shaft washer end side face |
| D1 |
≈ 1 034 mm
|
Shoulder diameter outer ring |
| B |
123 mm
|
Width shaft washer or length of shaft washer bore diameter that fits on shaft (bearings with a machined cage) |
| B1 |
324 mm
|
Height shaft washer + cage |
| C |
165 mm
|
Height housing washer |
| s |
462 mm
|
Distance from shaft washer end side face to pressure point |
| r1,2 |
min. 15 mm
|
Chamfer dimension shaft washer |
| da |
min. 1 080 mm
|
Diameter of shaft abutment |
|---|---|---|
| Da |
max. 1 185 mm
|
Diameter of housing abutment |
| ra |
max. 12 mm
|
Fillet radius |
| Basic dynamic load rating | C |
20 200 kN
|
|---|---|---|
| Basic static load rating | C0 |
93 000 kN
|
| Fatigue load limit | Pu |
5 850 kN
|
| Reference speed |
190 r/min
|
|
| Limiting speed |
360 r/min
|
|
| Minimum axial load factor | A |
820
|
| Mass bearing |
2 025 kg
|
