Spherical roller thrust bearings accommodate very heavy axial and considerable radial loads. They have the highest load rating of all thrust bearings, enabling compact, high power density bearing arrangements. By combining two or more spherical roller thrust bearings, it is possible to create a bearing arrangement that is either self-aligning, allowing misalignment of the shaft, or very stiff.
| d |
710 mm
|
Bore diameter |
|---|---|---|
| D |
1 220 mm
|
Outside diameter |
| H |
308 mm
|
Height |
| d1 |
≈ 1 110 mm
|
Outside diameter of shaft washer end side face |
| D1 |
≈ 917 mm
|
Shoulder diameter outer ring |
| B |
117 mm
|
Width shaft washer or length of shaft washer bore diameter that fits on shaft (bearings with a machined cage) |
| B1 |
298 mm
|
Height shaft washer + cage |
| C |
149 mm
|
Height housing washer |
| s |
415 mm
|
Distance from shaft washer end side face to pressure point |
| r1,2 |
min. 15 mm
|
Chamfer dimension shaft washer |
| da |
min. 965 mm
|
Diameter of shaft abutment |
|---|---|---|
| Da |
max. 1 070 mm
|
Diameter of housing abutment |
| ra |
max. 12 mm
|
Fillet radius |
| Basic dynamic load rating | C |
17 600 kN
|
|---|---|---|
| Basic static load rating | C0 |
76 500 kN
|
| Fatigue load limit | Pu |
5 000 kN
|
| Reference speed |
220 r/min
|
|
| Limiting speed |
430 r/min
|
|
| Minimum axial load factor | A |
560
|
| Mass bearing |
1 500 kg
|
