Spherical roller thrust bearings accommodate very heavy axial and considerable radial loads. They have the highest load rating of all thrust bearings, enabling compact, high power density bearing arrangements. By combining two or more spherical roller thrust bearings, it is possible to create a bearing arrangement that is either self-aligning, allowing misalignment of the shaft, or very stiff.
| d |
1 000 mm
|
Bore diameter |
|---|---|---|
| D |
1 670 mm
|
Outside diameter |
| H |
402 mm
|
Height |
| d1 |
≈ 1 531 mm
|
Outside diameter of shaft washer end side face |
| D1 |
≈ 1 270 mm
|
Shoulder diameter outer ring |
| B |
154.9 mm
|
Width shaft washer or length of shaft washer bore diameter that fits on shaft (bearings with a machined cage) |
| B1 |
389 mm
|
Height shaft washer + cage |
| C |
190 mm
|
Height housing washer |
| s |
599 mm
|
Distance from shaft washer end side face to pressure point |
| r1,2 |
min. 15 mm
|
Chamfer dimension shaft washer |
| da |
min. 1 350 mm
|
Diameter of shaft abutment |
|---|---|---|
| Da |
max. 1 490 mm
|
Diameter of housing abutment |
| ra |
max. 12 mm
|
Fillet radius |
| Basic dynamic load rating | C |
31 100 kN
|
|---|---|---|
| Basic static load rating | C0 |
140 000 kN
|
| Fatigue load limit | Pu |
8 650 kN
|
| Reference speed |
130 r/min
|
|
| Limiting speed |
260 r/min
|
|
| Minimum axial load factor | A |
1 900
|
| Mass bearing |
3 383 kg
|
