Product characteristics
| Type of light |
red light |
| Housing |
threaded type |
Application
| Function principle |
Diffuse reflection sensor |
Electrical data
| Operating voltage [V] |
10…36 DC; (“supply class 2” to cULus) |
| Current consumption [mA] |
20 |
| Protection class |
II |
| Reverse polarity protection |
yes |
| Type of light |
red light |
| Wave length [nm] |
624 |
Outputs
| Electrical design |
PNP |
| Output function |
light-on mode |
| Max. voltage drop switching output DC [V] |
2.5 |
| Permanent current rating of switching output DC [mA] |
200 |
| Switching frequency DC [Hz] |
800 |
| Short-circuit protection |
yes |
| Type of short-circuit protection |
pulsed |
| Overload protection |
yes |
Detection zone
| Range [mm] |
2…600; (white paper 200 x 200 mm 90% remission) |
| Setting range [mm] |
150…600 |
| Range adjustable |
yes |
| Max. light spot diameter [mm] |
50 |
| Light spot dimensions refer to |
at maximum range |
Operating conditions
| Ambient temperature [°C] |
-25…60 |
| Protection |
IP 65 |
Mechanical data
| Weight [g] |
53.6 |
| Housing |
threaded type |
| Dimensions [mm] |
M18 x 1 / L = 72 |
| Thread designation |
M18 x 1 |
| Materials |
housing: stainless steel (1.4404 / 316L); operator interface: TPE |
| Lens material |
|
Displays / operating elements
| Display |
| switching status |
1 x LED, yellow |
|
| Operating elements |
|
Electrical connection
| Connection |
Connector: 1 x M12; coding: A |
