$5,310.00
| Electrical design | NPN |
|---|---|
| Output function | normally open |
| Sensing range [mm] | 3 |
| Housing | threaded type |
| Dimensions [mm] | M12 x 1 / L = 60 |
| Special feature | Gold-plated contacts; Full-metal housing | |
|---|---|---|
| Application | Use in machine tools, coolants and lubricants | |
| Pressure rating [bar] | 100 | |
| Note on pressure rating |
|
| Operating voltage [V] | 10…30 DC |
|---|---|
| Current consumption [mA] | < 20 |
| Protection class | III |
| Reverse polarity protection | yes |
| Electrical design | NPN |
|---|---|
| Output function | normally open |
| Max. voltage drop switching output DC [V] | 2.5 |
| Permanent current rating of switching output DC [mA] | 100 |
| Switching frequency DC [Hz] | 100 |
| Short-circuit protection | yes |
| Type of short-circuit protection | pulsed |
| Overload protection | yes |
| Sensing range [mm] | 3 |
|---|---|
| Operating distance [mm] | 0…2.4 |
| Correction factor | steel: 1 / stainless steel: 0.6 / brass: 0.7 / aluminium: 0.6 / copper: 0.3 |
|---|---|
| Hysteresis [% of Sr] | 1…20 |
| Ambient temperature [°C] | -25…70 |
|---|---|
| Protection | IP 67; IP 68; (“Coolant”) |
| EMC |
|
||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| MTTF [years] | 1177 | ||||||||||
| Embedded software included | yes | ||||||||||
| UL approval |
|
| Weight [g] | 28.3 |
|---|---|
| Housing | threaded type |
| Mounting | flush mountable |
| Dimensions [mm] | M12 x 1 / L = 60 |
| Thread designation | M12 x 1 |
| Materials | housing: stainless steel (1.4404 / 316L); sensing face: stainless steel (1.4404 / 316L); LED window: PEI; lock nuts: stainless steel (1.4404 / 316L) |
| Tightening torque [Nm] | 15 |
| Full-metal housing | yes |
| Display |
|
|---|
| Items supplied |
|
|---|
| Pack quantity | 1 pcs. |
|---|
